Product Details:
Payment & Shipping Terms:
|
| Brand: | Forged | Material: | Molybdenum |
|---|---|---|---|
| Density: | 10.2g/cm3 | Purity: | Over 99.95% |
| Surface: | Ground/cold Rolling/pickling/alkali Cleaning | Application: | Vacuum Furnace |
| Highlight: | 99.95% Purity Molybdenum Metal,Molybdenum Plate High Temperature Resistance,Molybdenum Metal High Temperature Resistance |
||
99.95% purity Customized Molybdenum plate high temperature resistance rolling pickling alkali cleaning ground surface
Application
Molybdenum plate is used in electronics, aviation, aerospace, electric light source, heating element in vacuum furnace, heat insulation screen, molybdenum boat, molybdenum crucible, etc.
The company adopts a exclusive production process to produce hot and cold rolled high temperature molybdenum plate, sheet and strip products, which increase the crystallization temperature of molybdenum by 500℃ ~ 700℃, and meet the requirements of heat insulation screen material for vacuum furnace with the temperature of 1850℃.
Surface state: black board, alkali washing board plate , polished board plate,cold rolling.
operating temperature 1000-1800℃
Product information
| Item | molybdenum sheet plate from china |
| Standard | ASTM B386, GB/T3876 |
| Grade | Mo1, 361 |
| Material | 99.95% Molybdenum |
| Density | 10.2g/cm3 |
| Melting Point | 2610 Centigrade |
| Using temperature | 1400 Centigrade max. |
| Size | Thick 0.025mm min. x W600mm max. x L3000mm max. |
| Processing | Cold rolled, Stress relief annealing, Hot rolled |
| Colour | Black or bright |
| Package | Standard wooden case as your request |
Chemical requirements
| Element | Ni | Mg | Fe | Pb | Al | Bi | Si | Cd | Ca | P |
| Concentration(%) | 0.003 | 0.002 | 0.005 | 0.0001 | 0.002 | 0.0001 | 0.002 | 0.0001 | 0.002 | 0.001 |
| Element | C | O | N | Sb | Sn | Mo | ||||
| Concentration(%) | 0.01 | 0.003 | 0.003 | 0.0005 | 0.0001 | balance | ||||
