Product Details:
Payment & Shipping Terms:
|
| Type: | Refractory | Carbon Content: | High-Carbon |
|---|---|---|---|
| Advantage: | High Temperature Resistance | Sample: | Provided |
| Application: | Melting And Smelting | Composition: | SiC |
| Product Name: | Graphite Crucible | Crucible Graphite Application: | Melting And Smelting |
| Material: | High Pure Graphite Materials | Color: | Black |
| Height: | 380-1150 | Top Diameter: | 330-910mm |
| Max. Service Temperature: | 1650℃ | Heat Conductivity: | Excellent |
| Oxidating Resistance: | Excellent | ||
| Highlight: | aluminium high purity carbon graphite crucible,refractory aluminium high purity carbon graphite crucible,good heat conductivity graphite crucible small |
||
|
Parameter index of crucible
|
|||||
|
SIC
|
C
|
BULK DENSITY
|
APPARENT POROSITY
|
Modulous of Rupture
|
REFRATORINESS
|
|
≥ 40%
|
≥ 35%
|
≥2.2 G/CM3
|
≤15%
|
≥10Mpa
|
1790℃
|
|
Table size of clay graphite crucible
|
|||
|
No.
|
Height mm
|
Upper OD mm
|
Bottom OD mm
|
|
2#
|
100
|
90
|
50
|
|
10#
|
173
|
162
|
95
|
|
10#
|
175
|
150
|
110
|
|
12#
|
180
|
155
|
105
|
|
20#
|
240
|
190
|
130
|
|
30#
|
260
|
210
|
145
|
|
30#
|
300
|
237
|
170
|
|
40#
|
325
|
275
|
185
|
|
70#
|
350
|
280
|
190
|
|
80#
|
360
|
300
|
195
|
|
100#
|
380
|
325
|
225
|
|
120#
|
400
|
347
|
230
|
|
150#
|
435
|
355
|
255
|
|
200#
|
440
|
420
|
270
|
|
250#
|
510
|
420
|
300
|
|
300#
|
520
|
435
|
310
|
|
400#
|
690
|
510
|
320
|
|
500#
|
740
|
540
|
330
|
|
500#
|
700
|
470
|
450
|
|
800#
|
800
|
700
|
500
|
