Product Details:
Payment & Shipping Terms:
|
| Model Number: | TZM Molybdenum Alloy | Product Name: | TZM Molybdenum Plates |
|---|---|---|---|
| Variety: | Sheet, Plate, Rod, Cubes, Etc | Delivery State: | Machined, Polished Surface |
| Application: | Vacuum Furnace Or Sapphire Crystal,high Temperature Furnace | Chemical Composition: | 0.50% Titanium, 0.08% Zirconium,Mo |
| Density: | 10.2g/cm3 | ||
| Highlight: | Pure Molybdenum Alloy TZM,Vacuum Furnace Molybdenum Alloy TZM,Molybdenum Alloy MoLa |
||
Specifications:
| Commodity Name | TZM Molybdenum Plates |
| Surface | Ground Surface |
| Chemical Composition | Mo+0.4-0.55%Ti+0.06-0.12%Zr+0.01-0.04%C |
| General Properties |
Density:10.1g/cm3-10.15g/cm3 Recrystallization Temperature: 1425-1595°C Liquid Temperature:2620°C
|
| Application | TZM is widely used in the aerospace, aviation and other industries. It could be used as nozzle material, valve body, gas piping materials, tubes in the gate material, die casting molds, extrusion dies and high temperature furnace element and heat shield etc. |
| Advantages of TZM compared to pure molybdenum |
1. Above 1100°C tensile strength is aobut twice that of unalloyed molybdenum 2. Better creep resistance 3. Higher recrystallization temperature 4. Better welding properties. |
| Standard | ASTM B386 Type 364 |
