Product Details:
Payment & Shipping Terms:
|
| Brand: | Forged | Material: | Tungsten |
|---|---|---|---|
| Density: | 19.3g/cm3 | Purity: | Over 99.95% |
| Surface: | Ground/cold Rolling/pickling/alkali Cleaning | Application: | Vacuum Furnace |
| Operatig Temparature: | 1800-2500 | Working Condition: | Vacuum/inert Gas |
Applications:
used in electronic, electric light source, electric vacuum and other industries.
making up tungsten electronic board, tungsten boat, tungsten target material, tungsten heat insulation screen, tungsten heating element and other products, ion implantation parts,
electronic and semiconductor parts, tungsten sputtering target materials.
used to make electric light source parts and electric vacuum devices,heat screen of the
tungsten boat, high temperature or vacuum furnace.
| Tungsten product composition performance parameters | |||
| Type | The main content(%) | The density of(g/cm³) | Hardness(HV10) |
| MGPW | W≥99.95 | ≥19.1 | 400-460 |
| MGPWLA |
W≥98.8 La2O3:0.8-1.2 |
≥18.7 | 360-460 |
| MGPWSKA |
W≥99.9 K:(0.0030-0.015) |
≥18.9 | 360-460 |
| The thickness of the(mm) | The width of the(mm) | The length of the(mm ) | Roughness (Ra) |
| 1.0-3.0 | ≤300 | ≤800 |
0.4-0.8 |
| >3.0-10.0 | ≤500 | ≤1000 | |
| >10.0 | ≤300 | ≤1000 |
